Setting Up V-Series Appliances > Network interface configuration
Network interface configuration
Deployment and Installation Center | Web and Email Protection Solutions | v8.2.x
Applies to:
*
TRITON AP-WEB and Web Filter & Security, v8.2.x
*
TRITON AP-EMAIL, v8.2.x
*
V-Series appliances, v8.2.x
IMPORTANT: This topic has not yet been fully updated for Version 8.3. Those updates will be added soon.
Use the Configuration > Network Interfaces IPv4 and IPv6 pages to specify the IP address, subnet mask, default gateway, and DNS addresses for each network interface on the appliance.
*
Appliance Controller Interface (C)
*
Content Gateway Interfaces (P1 and P2)
*
Network Agent Interface (N)
*
Email appliance interfaces (E1 and E2, or P1 and P2)
*
Interface bonding
Web appliances with Content Gateway support IPv6 addresses for C, P1, P2, and N.
Email appliances do not support IPv6 addresses for E1 and E2.
For more information about IPv6 support, see Appliance Manager Help.
Click OK to save and apply new values in each section.
